Full-Height Turnstiles with Integrated Access Control
The Z217 rotating turnstile is specifically designed for high-security applications such as construction sites, industrial parks, and campuses. Its full-height enclosed structure prevents climbing or crawling through, virtually eliminating unauthorized intrusion.
Constructed from durable stainless steel, this turnstile offers waterproof, UV-resistant, cold-resistant, and heat-resistant properties, ensuring reliable operation both indoors and outdoors in all weather conditions. It seamlessly integrates with identification systems including facial recognition terminals and card readers, enabling intelligent access control and attendance management.
Key Features & Advantages
- Fully Enclosed Anti-Climb Design: Complete prevention of climbing or crawling through with security superior to swing gates or wing barriers
- Superior Environmental Adaptability: Waterproof, UV-resistant, cold-resistant, and heat-resistant with high IP rating for all weather conditions
- Smooth, Low-Noise Operation: Unique mechanism design ensures minimal noise, low mechanical wear, and extended service life
- Automatic Unlocking for Safety: Automatic unlocking during power failure with mechanical mode for free passage, fully compliant with fire safety regulations
- Automatic Reset & Anti-Tailgating: Automatic permission cancellation if user doesn't pass within preset time, preventing permission abuse
- Two-Way Passage Indicator: Bright red/green arrow indicator lights for clear status signals and pedestrian flow guidance
- Intelligent Attendance Management: Automatic working hour calculation, lunch break deduction, report generation, and payroll system integration
Technical Specifications
| Product Name |
Full Height Turnstile |
| Product Size |
1500mm * 1500mm * 2200mm (Customizable) |
| Traffic Speed |
30 People/Minute |
| Service Life |
≥5 Million Cycles |
| Channel Width |
600mm |
| Working Voltage |
AC220V±10%/50HZ 50W |
| Relative Temperature |
≤95% Not Condensing |
| Product Power |
100W |
| Opening Time |
0.5 Seconds |
| Ambient Temperature |
-30℃ to 70℃ |
| Work Environment |
Indoor and Outdoor |
| Protection Grade |
IP43, IP54 |
| Access Control Type |
RFID/IC/ID card, Face/Iris recognition, Fingerprint identification, QR code, Mobile phone/NFC, Password, Remote door opening |
| Communication Interface |
Relay switch signal/12V level signal/12V pulse signal with pulse width＞100ms; RS485 or TCP/IP |
| Barrier Material |
304 stainless steel round tube / 201 stainless steel with baked paint |
| Passage Frame |
304 stainless steel / 201 stainless steel with baked paint |
Frequently Asked Questions
What is a full height turnstile?
A full height turnstile is a security access gate that extends from the floor to the top of the passage, creating a complete physical barrier. It is commonly used in high-security locations where preventing unauthorized entry is important.
What is the difference between a full height turnstile and a tripod turnstile?
A tripod turnstile controls access with three rotating arms, while a full height turnstile provides a higher level of security by completely blocking the entrance area. Full height turnstiles are more suitable for factories, prisons, stadiums, and restricted facilities.
Can this turnstile work outdoors?
Yes. The stainless steel structure provides excellent durability and corrosion resistance, making it suitable for many outdoor applications. Additional weatherproof customization can also be provided.
Can it connect with facial recognition systems?
Yes. The turnstile supports integration with facial recognition, fingerprint scanners, RFID readers, QR code systems, and other third-party access control devices.
How many people can pass through the turnstile?
The capacity depends on the model and configuration, but full height turnstiles are designed for continuous high-frequency pedestrian access management.
Do you provide customization services?
Yes. We can customize size and passage width, material finish, access control integration, communication protocols, and installation requirements.
